Intro
The class E amplifier is classified as a switch mode amplifier similar to class D and F amplifiers. In these classes, the switching device doesn’t act as a linear component as it does in classes A, B, and C. Instead, it’s kept “on” (ideally \(V_{ds} = 0\) and \(R_{ds} = 0\)) or “off”(\(V_{ds} = f(\theta)\) and \(R_{ds}=\infty\)). It has the advantages of having an ideal efficiency of 100% because \(V_{ds}*I_{ds}\) is kept at 0 for all \(\theta\) by the pulse shaping network, realizable with stripline elements, and has a high maximum operating frequency for a given switching device be it a MOSFET, BJT, or the like. It also uses relatively few components and one of the capacitors is in parallel with the switching device meaning the device’s own capacitance becomes part of the network. With everything though, there are some disadvantages with using a class E amplifier. The Vds reaches a max voltage of about three times Vcc and the amplifier itself is highly nonlinear. A variation in the level of the input to the gate or base of the switching device doesn’t correlate well with the output power to the load. Not to leave this on a bad note, the class E amplifier is a great topology that has seen use in many places.
Where is/was it Used?
How I Came Across This and why I Built it
Design and Construction
Conclusion
Future
A full write-up with results is in progress.
Sources:
Colantonio, Paolo, Franco Giannini, and Ernesto Limiti. High Efficiency RF and Microwave Solid State Power Amplifiers. Chichester, U.K.: J. Wiley, 2009. Print. Cripps, Steve C. RF Power Amplifiers for Wireless Communications. Boston: Artech House, 1999. Print. Kazimierczuk, Marian K. RF Power Amplifiers. Chichester, West Sussex, U.K.: Wiley, 2008. Print. Reynaert, Patrick, and Michiel Steyaert. RF Power Amplifiers for Mobile Communications. Dordrecht: Springer, 2006. Print. Shirvani, Alireza, and Bruce A. Wooley. Design and Control of RF Power Amplifiers. Boston: Kluwer Academic, 2003. Print.
